DS1923 Hygrochron Temp/Humidity Logger iButton Discount 2025 Unisex

DS1923-F5

The DS1923 temperature/humidity logger iButton® is a rugged, self-sufficient system that measures temperature and/or humidity and records the result in a protected memory section. The recording is done at a user-defined rate. A total of 8192 8-bit readings or 4096 16-bit readings, taken at quidistant intervals ranging from 1s to 273hr, can be stored. Additionally, 512 bytes of SRAM store application-specific information and 64 bytes store calibration data. A mission to collect data can be programmed to begin immediately, after a user-defined delay, or after a temperature alarm. Access to the memory and control functions can be password protected. The DS1923 is configured and communicates with a host-computing device through the serial 1-Wire® protocol, which requires only a single data lead and a ground return. Every DS1923 is factory lasered with a guaranteed unique 64-bit registration number that allows for absolute traceability. The durable stainless-steel package is highly resistant to environmental hazards such as dirt, moisture, and shock. Accessories permit the DS1923 to be mounted on almost any object, including containers, pallets, and bags. A Shield/Umbrella is required to protect the top of the device from direct water droplets and rain.

FEATURES

Digital Hygrometer Measures Humidity with 8-Bit (0.6%RH) or 12-Bit (0.04%RH) Resolution
Operating Range: -20°C to +85°C; 0 to 100%RH (see Safe Operating Range Graph)
Automatically Wakes Up, Measures Temperature and/or Humidity, and Stores Values in 8KB of Data-Log Memory in 8-Bit or 16-Bit Format
Digital Thermometer Measures Temperature with 8-Bit (0.5°C) or 11-Bit (0.0625°C) Resolution
Temperature Accuracy Better Than ±0.5°C from -10°C to +65°C with Software Correction
Built-In Capacitive Polymer Humidity Sensor for Humidity Logging
Hydrophobic Filter Protects Sensor Against Dust, Dirt, Contaminants and Condensation

EXTREME CAUTION: A PROTECTION SHIELD/UMBRELLA MUST BE USED TO PROTECT THE TOP OF THE CASE FROM EXPOSURE TO LIQUIDS AND THE DEVICE MUST NOT BE SUBMERSED IN LIQUID. TO DO SO WILL CAUSE THE DEVICE TO MALFUNCTION AND INVALIDATE THE DEVICE WARRANTY

Sampling Rate from 1s Up to 273hr
Programmable Recording Start Delay After Elapsed Time or Upon a Temperature Alarm Trip Point
Programmable High and Low Trip Points for Temperature and Humidity Alarms
