100mm Monolithic Castor – Swivel Plate – 120kg – Stainless Steel – High/Low Temperature Outlet For Sale
Original price was: $46.05.$37.76Current price is: $37.76.
Description
Description
The MSP100/SP castor frame is a swivel plate type, with a double head race bearing filled with high/low temp grease, all constructed from the highest quality AISI 304 Stainless Steel, fully certified for uses in hygienic and food environments,
The 100mm diameter wheel is a monolithic compound & has a plain bore with a stainless steel axle bush (no bearing). Wheel hardness is similar to nylon.
These castors can safely operate between temperatures of between -40°C to +300°C !
These stainless steel, high/low temp castors are ideal for use on bakery racks, freezers, oven trollies & where hygiene is paramount.
These castors are RoHS & REACH compliant, also FDA certified for use in food and hygienic environments. Certification sheets available.
Versatile plate mount with slotted holes, meaning the standard mount size of 80mm x 60mm is achieved plus other variants, for in depth plate measurement click here –
Specifications
| Code: | MSP100/SP |
| Load per Castor: | 120kg |
| Wheel Diameter: | 100mm |
| Wheel Width: | 35mm |
| Bearing Type: | Plain Bore |
| Wheel Material: | Monolithic |
| Overall Height : | 128mm |
| Swivel Radius: | 92mm |
| Plate Size: | 100mm x 85mm |
| Bolt Hole Spacing: | 80mm x 60mm |
| Bolt Hole Size: | 9mm |
